Subfloor preparation
35
Subfloor preparation
Heating devices
ELECTRICAL HEATERS
«RED-HOT» 15 kW THREE-PHASE
Three-phase model. Hot air blower for gradual heating of big spaces
(more than 45 m2). Sturdy steel structure with anti-tip frame. Ambient
thermostat, adjustable temperature setting. Power: 5,000 to 15,000 W.
CE compliant.
For gradual heating of premises up to 30 m2. Rust-proof solid
metal structure.
Hot air pulse fan. Ambient thermostat. Safety sensor preventing
from overheating.
CE compliant.
Inclination
up to 14%
«RED-HOT» 3 kW
Not for use in
spaces of less
than 45 m²
R
eference
Power
Voltage Air flow Temperature
rise
Protection
grade
Noise
level Weight Current Dimension L x l x H
Price excl.
VAT
93475
1.65-3.3 kW 220 V - 50 Hz 288 m³/h 68 °C
IP24 50 dB 6 kg 14.3 A 255 x 250 x 398 mm
«RED-HOT VARIO» 3 kW
Hot air blower, for gradual heating of premises up to 30 m2. Sturdy
metal structure with anti-tip frame, inclination up to 14%. Ambient
thermostat, adjustable temperature setting from 0 to 40 °C. Automatic
stop in case of overheating.
CE compliant.
R
eference
Power Voltage Air flow Temperature
rise
Protection
grade
Noise
level Weight Dimension L x l x H
Price excl.
VAT
93477
3 kW 230 V - 50 Hz 400 m³/h 68 °C
IP24 50 dB 5.5 kg 298 x 330 x 387 mm
R
eference
Power Voltage Air flow Temperature
rise
Protection
grade
Noise
level Weight Dimension L x l x H
Price excl.
VAT
93478
15 kW 380-400 V -
50 Hz 1250 m³/h 82 °C
IP24 62 dB 15.3 kg 404 x 430 x 576 mm
OIL HEATER
«F-37» FUEL OIL HEATER
For heating rooms over long periods. Fixed output temperature approx.
250° C. Chimney-less hot air generator with compressor. Stainless steel
combustion chamber. Flame control by photoelectric cell. Reservoir opera-
ting time: approx. 10 hrs. Ideal for drying when used with a dehumidifier.
Operates on domestic fuel oil or diesel. Ambient thermostat.
CE.
Only for use in
ventilated locations
R
eference
Power
Voltage
Temperature
rise
Max. surface /
volume
Operating time Weight
Max. fioul
consumption
Price
excl. VAT
93444
37 kW 230 V - 50 Hz
68° C
900 m³ / 300 m²
10 hours
23.2 kg
+- 4 litres/h
